What Does 6S Mean in Drone Batteries?

A 6S drone battery consists of 6 cells connected in series, delivering a nominal voltage of 22.2V. It is one of the most widely used configurations for medium-sized UAVs.

Product Overview

Our 6S Drone Battery is engineered for industrial UAV applications requiring balanced power output, lightweight battery structure, and stable operational performance. The battery supports a wide range of drone systems including agricultural UAVs, FPV drones, aerial photography platforms, and mapping UAVs.

Designed with industrial-grade safety protection and optimized energy management, the battery helps improve flight efficiency and operational reliability.

Product Positioning

This battery solution is designed for lightweight and medium-sized UAV platforms requiring stable voltage output, efficient flight endurance, and reliable industrial performance.

Core Advantages

Stable Flight Performance

Provides reliable voltage output for smooth UAV operation.

Lightweight Energy System

Improves UAV maneuverability and payload efficiency.

Long Cycle Life

Supports continuous industrial UAV operations.

Flexible Compatibility

Compatible with multiple industrial and commercial drone platforms.

Industrial-Grade Reliability

Optimized for professional UAV applications.

Applications

Agricultural UAV

Suitable for spraying and crop monitoring drones.

FPV Drone

Supports racing and freestyle UAV systems.

Mapping UAV

Provides stable power for aerial survey operations.

Inspection Drone

Supports industrial monitoring and inspection tasks.

Technical Specifications

• Voltage: 6S
• Energy Density: 275Wh/kg–340Wh/kg
• Capacity: Customizable
• Cycle Life: 800–1000+ Cycles
• Operating Temperature: -20°C to 60°C
• Smart BMS: Optional
• High C-rate: Optional
• OEM/ODM Service: Available

Industry Challenges

• Limited endurance for medium-sized UAV systems
• Voltage instability affecting flight control
• Weight restrictions reducing payload efficiency

Our Solution

Our 6S UAV battery solution improves drone performance through:

• Lightweight industrial battery architecture
• Stable voltage output for reliable operation
• Long operational endurance
• Customized battery configurations for industrial UAVs

Advantages of 6S Drone Batteries

• Stable 22.2V output
• Wide compatibility with UAV systems
• Balanced performance and cost
• Suitable for medium payload drones

6S vs Other Configurations

Type	Voltage	Application
6S	22.2V	Medium UAV
12S	44.4V	Industrial drones
14S	51.8V	Heavy-duty UAV
18S	66.6V	Large UAV systems

Recommended Applications

• Agricultural spraying drones
• Mapping and surveying UAVs
• Inspection drones

Available 6S Battery Models

• 6S 22000mAh
• 6S 30000mAh
• 6S 36000mAh

XINGTO 6S Drone Battery All model parameters

Number	Energy density	Model	L*W*T(±3mm）	Weight(±200g)	Power	Full voltage	Rated voltage	C-rate
1	275Wh/kg	ZXGT001-6S16AH	75*48*195 mm	1.51kg	355.2wh	25.2V	22.2V	Peak discharge rate 10c Constant discharge rate 3-5c
2	275Wh/kg	ZXGT001-6S22AH	75*64*195 mm	1.98kg	488.4wh	25.2V	22.2V
3	275Wh/kg	ZXGT001-6S27AH	90*60*213 mm	2.38kg	599.4wh	25.2V	22.2V
4	275Wh/kg	ZXGT001-6S30AH	89*70*213 mm	2.65kg	666wh	25.2V	22.2V
5	275Wh/kg	ZXGT001-6S54AH	120*90*213 mm	4.70kg	1198.8wh	25.2V	22.2V
6	275Wh/kg	ZXGT003（HV)-6S25AH	63*90*210mm	2.47kg	592.5wh	26.7V	23.7V
7	275Wh/kg	ZXGT003（HV)-6S37AH	69*107*226mm	3.44kg	875.9wh	26.7V	23.7V
8	275Wh/kg	ZXGT003（HV)-6S40AH	74*107*226mm	3.81kg	978wh	26.7V	23.7V
9	300Wh/kg	ZXGT001-6S20AH	75*52*193 mm	1.70kg	444wh	25.2V	22.2V
10	300Wh/kg	ZXGT001-6S25AH	66*76*193 mm	2.02kg	555wh	25.2V	22.2V
11	300Wh/kg	ZXGT004-6S29AH	90*60*213 mm	2.38kg	643.8wh	25.2V	22.2V
12	310Wh/kg	ZXGT004-6S8.5AH	40*56*160mm	0.8kg	188.7wh	25.2V	22.2V
13	320Wh/kg	ZXGT002-6S18AH	49*76*188mm	1.47kg	399.6wh	25.2V	22.2V
14	320Wh/kg	ZXGT002-6S25AH	65*76*188mm	1.95kg	555wh	25.2V	22.2V
15	320Wh/kg	ZXGT001-6S33AH	90*65*217 mm	2.53kg	732.6wh	25.2V	22.2V
16	320Wh/kg	ZXGT002-6S46AH	46*146*255 mm	3.58kg	1021.2wh	25.2V	22.2V
17	320Wh/kg	ZXGT004-6S50AH	70*107*245mm	3.90kg	1110wh	25.2V	22.2V
18	320Wh/kg	ZXGT002-6S55AH	56*146*255 mm	4.16kg	1221wh	25.2V	22.2V
19	320Wh/kg	ZXGT002-6S67AH	67*146*255 mm	5.08kg	1487.4wh	25.2V	22.2V
20	330Wh/kg	ZXGT003-6S14AH	52*62*175 mm	1.17kg	310.8wh	25.2V	22.2V
21	330Wh/kg	ZXGT002-6S22AH	56*76*188mm	1.72kg	488.4wh	25.2V	22.2V
22	330Wh/kg	ZXGT002-6S30AH	76*76*188mm	2.25kg	666wh	25.2V	22.2V
23	330Wh/kg	ZXGT001-6S36AH	69*90*213 mm	2.7kg	799.2wh	25.2V	22.2V
24	340Wh/kg	ZXGT004-6S28AH	76*67*194 mm	2.05kg	621.6wh	25.2V	22.2V
25	340Wh/kg	ZXGT004-6S40AH	92*69*213 mm	2.77kg	888wh	25.2V	22.2V
26	370Wh/kg	ZXGT001-6S108AH	76*120*395mm	6.82kg	2397.6wh	25.2V	22.2V	Constant discharge rate 1C
27	400Wh/kg	ZXGT003-6S40AH	65*90*213mm	2.5kg	888wh	25.2V	22.2V	Peak discharge rate 10c Constant discharge rate 2c
28	400Wh/kg	ZXGT003-6S44AH	75*92*213mm	2.77kg	965.7wh	25.2V	22.2V
29	400Wh/kg	ZXGT003-6S50AH	55*125*245mm	3.2kg	1110wh	25.2V	22.2V
30	400Wh/kg	ZXGT003-6S74AH	55*154*294mm	4.44kg	1642.8wh	25.2V	22.2V
31	400Wh/kg	ZXGT003-6S82AH	59*154*294mm	4.82kg	1820.4wh	25.2V	22.2V
32	500Wh/kg	ZXGT004-6S22AH	46*76*188 mm	1.34kg	501.6wh	25.8V	22.8v	Charging： 0--45° / 0.2C                       discharge：                      -20°--0°/0.3C              0--45°/1C
33	500Wh/kg	ZXGT004-6S25.5AH	52*76*188 mm	1.42kg	581.4wh	25.8V	22.8v
34	500Wh/kg	ZXGT004-6S49.5AH	74*92*208 mm	2.56kg	1128.6wh	25.8V	22.8v
Other models can be customized

FAQ

Q: Is the battery suitable for agricultural UAVs?

A: Yes. It supports agricultural spraying and monitoring applications.

Q: Can the battery support FPV drones?

A: Yes. The battery is suitable for FPV racing and freestyle UAV systems.

Q: Do you provide OEM/ODM customization?

A: Yes. Customized voltage, connectors, and capacity options are available.
